1. Simpler Structure.
2. Stable performance.
3. Easy to operate.
4. Low power consumption.
| Model | Max Feeding Size (mm） |
Capacity (TPH) | Power (KW) |
Obliquity (°) | Feeding Chute Size(mm) | Dimension (mm) |
| GZ0816 | 250 | 100-250 | 1.1×2 | 10-25 | 800×1600 | 1720×950×720 |
| GZ1016 | 300 | 150-280 | 1.5×2 | 10-25 | 1000×1600 | 1720×1160×735 |
| GZ1218 | 350 | 225-420 | 2.2×2 | 10-25 | 1200×1800 | 2050×1410×820 |
| GZ1422 | 400 | 350-650 | 3.0×2 | 10-25 | 1400×2200 | 2410×1730×960 |
| GZD650×2300 | 400 | 80-100 | 1.1×2 | 10-20 | 650×2300 | 2300×1360×780 |
| GZD750×2500 | 450 | 100-130 | 1.5×2 | 10-20 | 750×2500 | 2500×1460×780 |
| GZD-50×3000 | 500 | 120-150 | 3×2 | 10-20 | 850×3000 | 3110×1800×1600 |
| ZSW380×95 | 550 | 100-180 | 11 | 0-10 | 3800×960 | 3800×1640×1320 |
| ZSW490×110 | 650 | 150-400 | 15 | 0-10 | 4900×1100 | 4980×1830×1320 |
| ZSW600×130 | 780 | 400-700 | 22 | 0-10 | 6000×1300 | 6082×2580×2083 |
| ZSW600×150 | 850 | 500-900 | 30 | 0-10 | 6000×1500 | 6086×2662×1912 |
| ZSW600×180 | 1050 | 700-1500 | 37 | 0-10 | 6000×1800 | 6310×3262×2230 |
Eccentric shafts, gears, bearings, springs, grate plates, vibration exciters, motors, etc.
